T-/C-SeriesPanel

Versatile. Compact. Powerful

Terminal and controller designs with touch screen

The Power Panel T-Series terminal version and the Power Panel C-Series controller version, both versions are equipped with an analog resistive touch screen. Equipped with an embedded browser, Power Panel T30 terminal devices are fully web-compatible and can also be used as a Visual Components client. Screens TFT display ranging from 4.3″ to 10.1″ and comes with 2 Ethernet interfaces, 2 USB ports and an extensive array of configuration options. High-performance HMI with a wide range of connection options

Description

The Power Panel C70 controller version is equipped with a 333 MHz Intel Atom CPU, 256 MB DDRAM, 16 kB FRAM and 2 GB onboard flash drive. This controller provides a built-in touch screen and is being offered in three display sizes ranging from 5.7″ to 10.1″. The Power Panel C70 achieves cycle times as fast as 1 ms. POWERLINK and standard Ethernet, 2x USB 2.0 and X2X Link, as well as optional RS232, RS485 and CAN interfaces meet all connection requirements.

They also have no hard disks, fans or batteries, which makes them maintenance-free. The front of the panel provides IP65 protection, making these devices extremely well-suited for harsh industrial environments.

Touch button

An integrated button on the lower right corner of the monitor area is part of the panel overlay design. This touch button can be included in the visualization program. This is a distinctive element for your visualization application that makes it possible, for example, to elegantly implement home or help functions.

Models

Power Panel T-Series and C-Series models are available in portrait and landscape format. The touch button is located optimally in the lower right corner. No matter which format you select, the button is always in the right position.

Overlay design

Anthracite gray with pinstripes or aluminum white with pinstripes: The perfect color for nearly all installations, available in both portrait and landscape format. These stylish pinstripe colors accentuate the quality of your visualization device and machine.
